The TDP-247 series direct thermal label printer offers best-in-class speed and high-resolution capabilities, along with a rugged, reliable design that has become the hallmark of the TSC printer family. TTP-246M/344M Bar Code Printer Service Manua 3.12.2 TTP-246M & 344M PCB Bottom Side Stepping Motor Driver IC. Page 27: Mechanism TTP-246M/344M Bar Code Printer Service Manua 4. Cara kalibrasi Printer Barcode TSC TTP-244. Kalibrasi pada Printer Barcode TSC dilakukan agar sensor printer dapat membaca jarak antar label barcode sehingga pencetakan barcode dapat tepat berada ditengah label. Jarak antar label dapat berupa GAP atau garis hitam (black mark) dengan lebar 2 milimeter atau 0,08 inchi. The TTP-244 Pro is ideal for customers looking for a high quality barcode printer, coupled with low ownership costs. The TTP-244 Pro is competitively priced, comes with a two-year warranty, and accommodates a 300-meter-long ribbon, which keeps both daily and lifetime operating costs lower than other comparable printers.
Pop quiz: how long does it usually take the TSC tech support team to fix print quality issues?
- 30 minutes
- 30-60 seconds
You’re probably used to 30 minutes, right? Isn’t that how long it usually takes for different companies to resolve other hardware or software issues?
The problem? This takes time—time you may not have. Time spent better elsewhere.
So what’s the actual answer?
Oftentimes, it’s the second option—just 30-60 seconds.
Sounds crazy, right? But it’s true.
Here’s how.
DiagTool
We briefly talked about DiagTool back in May 2017, when we discussed 4 powerful TSC tools you probably don’t know exist, but as a reminder, this is our Windows-based utility program that our tech support team uses to explore and configure TSC printer settings.
Or in layman’s terms, it’s the tool we use to quickly and remotely troubleshoot and resolve any issues you’re experiencing.
DiagTool Features
The great thing about DiagTool is that you don’t need to install it at all. No log-in is needed, either. It’s only 1 megabyte in size, downloads within 30 seconds, and easily opens right there, allowing our tech support team to see what’s going on.
After DiagTool is downloaded, you and our tech support team have complete diagnostics on your printer. Anything from the simple features—print speed, darkness, paper size, etc.—to printer settings, status, and advanced calibrations are shown.
Printer Configuration
On your main screen, you’ll see one of the main features called Printer Configuration:
The Set Printer Functions (see above) help with things like Ethernet Setup, Printer Resets, and Factory Defaults.
We can also look at your Printer Status:
That way, we can tell if, for example, there’s a paper jam, the printer is out of paper, or there’s a ribbon encoder error.
Bitmap Font Manager
Another helpful feature is the Bitmap Font Manager. This pertains, of course, to your font. By using this feature, we can select your specific font and encode it.
Overall, Printer Configuration and Bitmap Font Manager are just some of DiagTool’s many features that we use to quickly troubleshoot and fix printer issues.
Why Do We Need DiagTool?
There are three main reasons why DiagTool is extremely important for tech support:
- It is a more user-friendly tool to realize printer settings/status.
- We can relieve any difficulties in communicating with our customers.
- We can control the printer remotely, making it much easier for us to resolve your printer issues within a short amount of time.
How to Get DiagTool
To download this tool, go to Support & Downloads: https://www.tscprinters.com/EN/support/Index/
Then choose your printer model.
After you’ve filled out this information, you will reach a specific page for the printer model you’ve chosen.
For example, the TDP-225 Series:
Scroll down to Utilities.
Click on the v button to expand it.
Scroll down to where it says “Diagnostic Tool.” This is DiagTool. You can choose the right utility version based on the firmware or module you are using. (Questions about which DiagTool version to choose or which firmware you are using? Get in touch with us today!)
Next, click Download.
The tool should download within 30 seconds or less.
Click on the version you’ve downloaded, like DiagTool_V119, and it will open!
Conclusion
So if you ever run into any printer issues, don’t hesitate to call our tech support team; we’re here for you!
Note: This post was originally published in July 2017. It has been updated and revised for relevance.
How To Calibrate Tsc Ttp 244 Pro Printer
Any questions about DiagTool? Have you ever called tech support and seen it in action?
**This tutorial explains configuring a barcode label printers for MS Windows only but you can use references for a broad understanding of what needs to be done in an Apple environment**
Configure Printer
The following steps will guide you to setup your printer to print Primaseller generated barcodes:
- Install the printer drivers/software from the CD/DVD you received with your printer
- For installation, please follow the guidelines provided by the printer’s vendor
- After installation, go to Devices and Printers and select your printer in General Settings.
- Click on Printing Preferences to open preferences
- In the Page Setup tab, add a new stock with appropriate dimensions of your paper roll in inches or any unit available in the options
- Add the Label size and Exposed Liner Width. Although these are standard values, if during printing the label’s left/right margins get cut off, you will need to do some ‘hit & trial’ with the values here to set the margins correctly. Printing two labels in a row?
We generate a PDF of two labels as a single page and hence the label width of the printer config should be twice of the actual label when printing two in a row.
- Click OK to save the new stock created. Set the newly created configuration as default configuration to print Primaseller generated labels.
- Now on Primaseller, set the label template with dimensions that match your page setup dimensions. (Navigation: Settings > Product > Barcode Labels)
- Navigate to the Inventory section from the left panel under Products. Click on the barcode icon next to the SKU for which you want to print the barcode.
- Select the relevant label template and paper roll style. Provide the number of barcode labels to be generated, and click on Generate Labels.
- Primaseller will generate a PDF file which can be fed to the printer for printing labels.
Optimal Configuration Settings
Thermal printer configuration settings that usually work best are depicted through the following screenshots:
Note
- Test your barcode with only 1 or 2 labels first to make sure you are getting accurate prints based on your settings
- In case any of the margins get cut off, then repeat step numbers 3 to 4 (till you reach Printing Preferences) and click on Advanced Options.
- Set your vertical/horizontal offsets hereThe more accurate the dimensions you provide, the more accurate will be the barcodes you print.
- These settings are with respect to TSC TTP-244 Plus printer and may vary depending on the manufacturer and model of your printer.
